Large Format Digital Fabric Printing Machines

Large format 3.2m digital fabric printing machine 600sqm / hour

Feature of this machine:

1. Long life of printhead :3-5 years,can repair.
2. Avaiable:carpet,beding,curtain
3. Fast speed: 600sqm/hour
4. Large format for beding ,curtain: 3.2m
5. 24 hours running
6. Daily output:2500m/day
7. Direct printing
8. Pigment ink availble

A. Main specifications:

B. Description:

1) Functions:

• Separate electric control cabinet
• Separate ink supply system
• Degassing system reduces print head clogging
• Variable drop size (10-30pl) gives perfect clarity
• Bianco fabric feeder & Driver (optional)
• Super dryer (optional)

2) Ink types:

• Acid inks : on polyamide lycra, wool, silk
• Pigment ink : any kind of fabric
• Reactive inks : on all natural fibers such as cotton,silk,wool,etc
• dissperse inks : directly onto polyester and blends

3) Performance: carpet,curtain,sofa fabric,hometextile

4) Main parts & systerm:

• Printhead:starifire 1024
• Rip Software:TEXPRINT
• Servo motor Japan Panasonic& speed reducer German .
• Fabric transportation: SwissHabasit industrial belt.
• Germany printhead moving guider .
• Machine body ,operating platform
• Printing control and operating system
• Ink supply system
• Belt cleaning systerm
• Fabric feeding and taking up systerm
• Transducer & photoelectric sensor system, while fabric not flat or upwarp , it will alarm, and printhead will stop working.One set of this system installed beside belt,another one beside printhead.
• Belt-transporting system,integrated fabric feeding & take-up system,fabric spreading , fabric entry unit.
• Belt cleaning system:Auto brush & sponge-roller washing system belt wiping system.
• Ink supply:peristaltic pump supply,degassing NEG pressure system

C. Service:

1) Quality Guarantee:

The whole set of machine guarantee is 1 year. The print head is half year.We offer flexible extended

warranties if needed.

2) Installation training service:

We dispatch technician to your factory for installation ,testing and training.

D. Enviroment request:

Temperature is 15~30 ℃ and Humidity at 50%~70%.

Beijing Silk Road Enterprise Management Services Co.,Ltd.

We are a professional high - tech manufacturer specializing in developing, producing, and marketing digital textile printing machine. We have an independent R & D department, supporting with a full range of testing equipment, as well as advanced software and hardware.

The R & D team have 15 years experienced in this domain and senior technical personnel as core force, which provided a solid guarantee for product development.

Digital printer list:

----Digital textile printer ,

1) Ricoh gen5 speed: 120-300 m2/hour

2) Epson print head . print speed: 25-100 m2/hour

3) SG ( starfire 1024 ) speed: 200-600 m2/hour

----Digital carpet printer

 1) 16-32 heads of printer 2.2m /3.2m

 2)  32 heads of printer 4.2m

---- Machine can print width:

1) 1.8m

2) 2.2m

3) 3.2m

4) 4.2m
