1. Print speed:120m2/hour
2. Ink type:reactive,disperse or acid ink,pigment ink
3. Print color:C,M,Y,K,LC,LM,orange,grey,etc.

ometextile Printing Large Format Digital Printing Machine 3.2M Epson Head

A. Main specifications:

1. Plate Type:Flatbed Printer
2. Usage:Cloths Printer,carpet printer
3. print head: Epson dx5
4. fabric available:cotton,polyester,silk ,wool ,carpet,etc.
5. Print software:neostampa
6. Print thickness: 15-50mm
7. Max.printing width:3200mm
8. Power consumption:printer:12kw,dryer 30kw
9. Ink supply system:peristaltic pump supply,degassing NEG pressure system
10. Dry unit:Aluminum foil heater,infrared heater and hot fan heater
11. Print head clean system:positive pressure and wiper
12. Power voltage:380v,3-phase-4-wire

B. Description:

1) Print fabric sample:

hometextile,carpet,curtain,sofa fabric ect.

2) Main parts & systerm:

1. Servo motor Japan Panasonic& Germany speed reducer .
2. Fabric transportation: SwissHabasit industrial belt.
3. Germany printhead moving guider .
4. Machine body ,operating platform
5. Transducer & photoelectric sensor system, while fabric not flat or upwarp ,it will alarm,and printhead will stop working.One set of this system installed beside belt,another one beside printhead.
6. Belt-transporting system,integrated fabric feeding & take-up system,fabric spreading ,fabric entry unit.
7. Printing control and operating system
8. Belt cleaning system:Auto brush & sponge-roller washing system belt wiping system.

C. Application show

D. QUESTION

1. How many specification our factory produce?

------3 kinds of printhead:

1)Kyocera (Japan),

2)SG(starfire 1024)

3)Epson DX5,DX7

-----machine width:

1) 1.8m

2) 3.2m

Kyocera is more high resolution than SG.it’s depend on the level you can accept for your design.

2. How many operators for one set machine?

Need two persons.

3. Does print head need to washing?

It automatic self-washing.

4. Does the belt need to washing?

It has washing systerm ,washing while printing.

5. how is the produce processing?

Coating--printing---washing--steaming-drying and shaping

Poly can be print directly on the fabric,then use heat transfer to develop the color to be more shinning.

Beijing Silk Road Enterprise Management Services Co.,Ltd.

We are a professional high - tech manufacturer specializing in developing, producing, and marketing digital textile printing machine. We have an independent R & D department, supporting with a full range of testing equipment, as well as advanced software and hardware.

The R & D team have 15 years experienced in this domain and senior technical personnel as core force, which provided a solid guarantee for product development.

Digital printer list:

----Digital textile printer ,

1) Ricoh gen5 speed: 120-300 m2/hour

2) Epson print head . print speed: 25-100 m2/hour

3) SG ( starfire 1024 ) speed: 200-600 m2/hour

----Digital carpet printer

 1) 16-32 heads of printer 2.2m /3.2m

 2)  32 heads of printer 4.2m

---- Machine can print width:

1) 1.8m

2) 2.2m

3) 3.2m

4) 4.2m
